Equipment Model
|
HMC-24
|
HMC-32
|
HMC-36
|
HMC-48
|
HMC-64
|
HMC-80
|
|
|
Total Filtration Area m²
|
20
|
25
|
30
|
40
|
50
|
64
|
|
|
Filtration Velocity m/min
|
1.0-2.0
|
||||||
|
Air Volume m³/h
|
1200-2400
|
1500-3000
|
1800-3600
|
2400-4800
|
3000-6000
|
3840-7680
|
|
|
Quantity of Filter Bag
|
24
|
32
|
36
|
48
|
64
|
80
|
|
|
Specification and Material of Filter Bag
|
130*2000mm
|
||||||
|
Air Outlet Dust Concentration mg/m³
|
≤30
|
||||||
|
Beard Negative Pressure Pa
|
5000
|
||||||
|
Equipment Running Resistant Pa
|
800-1200
|
||||||
|
Injection Pressure Mpa
|
0.4-0.6
|
||||||
|
Electromagnetic
Pulse Valve
|
Specification
|
DMF-Z-25(G1")
|
|||||
|
quantity
|
4
|
4
|
6
|
6
|
8
|
8
|
|
|
Induced Draft Fan Model
|
4-72-2.8A
|
4-72-3.2A
|
4-72-3.6A
|
4-72-3.6A
|
4-72-4A
|
4-72-4.5A
|
|
|
Power of Motor
|
1.5kw
|
2.2kw
|
3kw
|
4kw
|
5.5kw
|
7.5kw
|
|
Botou Xintian Environmental Protection Equipment Co., Ltd has a superior geographical position, West 106 National Highway, North Shihuang Expressway, East 104 National Highway, Jingfu Expressway, BeijingShanghai Railway, Highway and Railway crisscross, and the traffic is very convenient. The lo mation of traffic network provides a time guarantee for the transportation and after-sales service of products.
